Description
The Optrel Panoramaxx CLT Black Welding Helmet combines panoramic visibility with Crystal Lens Technology 2.0 for one of the clearest welding views available.
Designed for professional welders, fabrication shops, pipe welding, and industrial applications, the Panoramaxx CLT delivers an ultra-bright light state, automatic adaptive shading, and all-day comfort with Optrel’s advanced IsoFit® headgear system.
Features
Crystal Lens Technology 2.0
Advanced CLT technology provides an exceptionally bright and true-color light state for improved weld puddle visibility and precision.
Ultra-Bright Shade 2.0 Light State
One of the brightest passive viewing states available in a professional welding helmet, improving visibility before and after welding.
Panoramic XXL Field of View
Offers up to 6.3 times larger viewing area compared to traditional 100 x 50 mm welding helmets for enhanced awareness and weld accuracy.
ShadeTronic® Auto-Shading
Automatically adjusts the shade level based on arc brightness and welding conditions for uninterrupted workflow.
FadeTronic® Technology
Smooth dark-to-light transition helps reduce eye fatigue during repetitive welding tasks.
True Color Visibility
Provides realistic color recognition and improved contrast without the heavy green tint found in older welding lenses.
5-Sensor Arc Detection
Five sensors provide reliable arc detection for low-amp TIG welding and difficult working environments.
Grinding Mode
Integrated grinding mode allows easy switching between welding and grinding applications.
No-Fog Nose Cut-Out Design
Patented nose cut-out design separates the breathing zone from the lens to reduce fogging.
IsoFit® Headgear
Advanced 3D adjustable headgear system improves comfort, stability, and weight distribution during long shifts.
Rechargeable Battery System
Rechargeable lithium-polymer battery charges through welding light or Micro USB charging.
Lightweight Construction
Designed for reduced neck fatigue and extended all-day welding comfort.
High Impact Protection
Provides reliable protection against high-speed particle impact and demanding industrial environments.
Specifications
| Specification | Details |
|---|---|
| Light State | Shade 2.0 |
| Automatic Shade Range | Shade 4–12 |
| Manual Shade Range | Shade 7–12 |
| Sensors | 5 |
| Optical Classification | EN379 1/1/1/2 |
| Switching Speed | 0.090 ms |
| Power Supply | Solar + Li-Polymer Battery |
| Charging Method | Micro USB |
| Battery Life | 300–500 Charging Cycles |
| Weight | Approx. 600g |
| Viewing Area | Up to 6.3x Larger Than Standard Helmets |
| Sensitivity Adjustment | Continuous + Super High Mode |
| Operating Temperature | 14°F to 131°F |
| Warranty | 2 Years + Optional 1-Year Extension |
Applications
- Stick Welding (SMAW)
- MIG/MAG Welding (GMAW)
- Flux-Cored Welding
- TIG Welding (GTAW)
- Plasma Welding
- Plasma Cutting
- Gas Welding
- Grinding Applications
- Structural Steel Fabrication
- Pipe Welding
- Industrial Manufacturing
- Heavy Fabrication Shops
- Overhead Welding Applications
Included in the Box
- Panoramaxx CLT Black Welding Helmet
- IsoFit® Headgear
- Storage Bag
- Micro USB Charging Cable
- Front Cover Lens
- Warranty Card
- Operating Instructions
Frequently Asked Questions
What makes the Panoramaxx CLT different from other welding helmets?
The Panoramaxx CLT combines panoramic visibility with Crystal Lens Technology 2.0, delivering one of the brightest and clearest welding views available.
Is this helmet suitable for TIG welding?
Yes. The 5-sensor system is designed for low-amperage TIG welding and precision welding applications.
Does the helmet automatically adjust shade levels?
Yes. ShadeTronic® technology automatically adjusts the shade level based on arc brightness and working conditions.
Can the helmet be used for grinding?
Yes. The integrated grinding mode allows quick transitions between welding and grinding tasks.
Is the battery rechargeable?
Yes. The helmet uses a rechargeable lithium-polymer battery that charges through solar energy or Micro USB.
Does the helmet help reduce fogging?
Yes. The patented nose cut-out design helps separate breathing airflow from the lens area to reduce fogging.
Is the helmet comfortable for all-day use?
Yes. The lightweight design combined with the IsoFit® headgear system helps reduce neck strain and improve comfort.
What welding processes is this helmet designed for?
The Panoramaxx CLT supports MIG, TIG, Stick, Flux-Cored, Plasma, and grinding applications.
