Aardwolf 180° Rotation Vacuum Lifters — 160 kg / 353 lbs.
.spec-table { width: 100%; border-collapse: collapse; font-size: 14px; margin-bottom: 24px; } .spec-table td { padding: 8px 12px; border: 1px solid #e0e0e0; vertical-align: top; } .spec-table td:first-child { font-weight: bold; width: 40%; background: #f5f5f5; } .spec-table tr.spec-group td { background: #222; color: #fff; font-weight: bold; text-transform: uppercase; font-size: 12px; letter-spacing: 1px; }
Available in Two Variants: ARV-180 (Pneumatic) | AERV-180 (Electric)
Product Overview
The Aardwolf 180° Rotation Vacuum Lifter series is a crane- and hoist-integrated vacuum lifting system designed for handling flat, smooth, nonporous materials up to 160 kg (353 lbs). Both variants provide full 180° rotation and are built for demanding use in stone fabrication shops, glass handling, and job site installation work.
Both models share the same core design: a high-performance vacuum pump for strong, stable suction; adjustable vacuum pads with integrated measuring scales and locking handles; a self-balancing system; an integrated support stand for stable storage; and audio-visual safety alerts for vacuum pressure monitoring. The key difference is power source — the ARV-180 runs on compressed air (pneumatic), while the AERV-180 runs on 24V electric power with a quick-swap battery for cord-free operation.
Both lifters are compatible with Aardwolf cranes and hoists (sold separately), and an optional dual-position fabrication table is available as an accessory.
Ideal Applications
- Stone slab handling and fabrication
- Glass panel lifting and installation
- Large-format flat material positioning
- Shop and job site use with cranes or hoists
- Any smooth, nonporous flat load up to 353 lbs
Shared Features — Both Variants
180° Rotation
Full 180° rotation with linear control, allowing operators to adjust rotation speed and angle precisely for positioning loads in tight spaces or at specific orientations.
High-Performance Vacuum Pump
Provides strong, stable suction for reliable attachment to a wide range of smooth, flat materials throughout the work cycle.
Self-Balancing System
Keeps loads level and stable during lifting and transport, reducing operator effort and improving handling accuracy.
Adjustable Vacuum Pads
Pads are repositionable with integrated measuring scales and locking handles for fast, accurate setup to match different load sizes and configurations.
Safety Monitoring — Audio-Visual Alerts
Real-time alerts for vacuum pressure status give operators immediate warning of any loss of suction before it becomes a safety incident.
Integrated Support Stand
Built-in stand keeps the lifter stable and upright when not in use — no separate storage equipment required.
Ergonomic Handle
Designed for comfortable operation during extended use in both workshop and job site environments.
Variant Comparison
| ARV-180 — Pneumatic | AERV-180 — Electric | |
| Power Source | Compressed air (pneumatic) | 24V quick-swap clip-in battery |
| Working Load Limit | 160 kg / 353 lbs | 160 kg / 353 lbs |
| Rotation | 180°, linear control | 180°, linear control |
| Best For | Shops with compressed air infrastructure | Job sites or locations without air supply |
| Continuous Operation | While air supply is connected | Quick-swap battery for uninterrupted use |
| Material Surface | Smooth, nonporous | Smooth, nonporous |
| Crane / Hoist Compatible | Yes | Yes |
ARV-180 — Pneumatic Variant
The ARV-180 is the pneumatic version, powered by a standard compressed air supply. It is well suited for workshop environments where air lines are already in place, offering continuous operation without battery management. All rotation and vacuum functions are operator-controlled through the integrated control panel.
AERV-180 — Electric Variant
The AERV-180 is the electric version, running on a 24V quick-swap clip-in battery. The battery can be replaced within seconds, enabling continuous operation without downtime. A cooling fan supports high-duty cycles, and an electric cylinder provides smooth, precise rotation. This variant is ideal for job sites or locations where a compressed air supply is not available.
Technical Specifications
| General | |
| Working Load Limit (WLL) | 160 kg / 353 lbs. |
| Rotation | 180°, linear control |
| Material Surface | Smooth, nonporous |
| Crane / Hoist Integration | Yes — designed to mount directly to cranes and hoists |
| ARV-180 — Pneumatic | |
| Model | ARV-180 |
| Power Source | Pneumatic (compressed air) |
| AERV-180 — Electric | |
| Model | AERV-180 |
| Power Source | 24V quick-swap clip-in battery |
| Lifting Mechanism | Electric cylinder |
| Net Weight | 289 lbs |
| Cooling | Integrated cooling fan for high-duty cycles |
| Accessories (Optional) | |
| Compatible Cranes & Hoists | Aardwolf cranes and hoists (sold separately) |
| Fabrication Table | Dual-position fabrication table (optional accessory) |
Note: Both variants are designed for smooth, nonporous surfaces only. Always verify load surface compatibility before use. Contact us for current pricing — these products are available by quote.
